Structure
- Stand alone and add-on vertical section
- EEMAC Type 1 and 12 enclosures
- Dimension - 90"Hx20"Wx20"D
- 10" Horizontal wireways - top & bottom
- Back to Back construction available
- Removeable top cover plates
- Floor sills and lifting angles - standard
- Exterior finish -ASA61 grey - standard
- Interior finish - brilliant white - standard
Bus Bars
- 600V max
- 600A copper horizontal bus - standard
- 1200A copper horizontal bus - optional
- 400A copper vertical bus - standard
- Copper ground bus - standard
- Copper neutral bus - optional
- Bus bracing 22KAIC symmetrical - standard
- Bus bracing 42KAIC symmetrical - optional
Starter and Feeder Units
- Fusible and circuit breaker type feeder units
- Fusible and circuit breaker type FVNR, FVR, 2-speed, soft start, reduced voltage and solid state drive motor control units
- Bi-metal or electronic overload protection
- PLC, lighting and relay panels available
- Lamacoid nameplates engraved as specified
- Wiring class I, type A & B
Incoming Line
- Incoming terminal connections
- Main molded case circuit breaker
- Main fusible switch
Replacement Starter & Feeder Units
- Factory original installations & mounting
- Plug-in starter design thru size 4
- Plug in Feeder design through 225A
- Fused or circuit breaker protection
- Heavy duty GE motor starters,circuit breakers and pilot devices
Solid State Unit Technology
- Variable frequency Drives
- Soft start controllers
- PLC panels
- Vacuum Contactors
- Electronic overload relays
- Electronic current sensing circuit breakers
